Novaris KP1-T Telephone Protector 10kA 200VDC KRONE LSA-PLUS 21mm W 9.5mm D 53.3mm H ABS Black EDM IP20

Product Code: KP1-T

  • Rated for 200 VDC, 10 kA current
  • Compact size: 21mm x 53.3mm x 9.5mm
  • Fast response time under 5 ns
  • Operates in -40 to 85°C range
  • Compliance with IEC, UL, ITU-T standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 21W x 53.3H x 9.5D
Operational Temperature Range (°C) -40 to 85
Maximum Load Current - I? (A) 0.25
Weight (g) 6.5
Maximum Continuous Voltage DC (V) 200
Maximum Continuous Voltage AC (V) 140
Maximum Discharge Current (8/20µs) (kA) 10
Product Type Telephone Protector
Brand NOVARIS
Capacitance 18 pF
Connection Type KRONE LSA-PLUS
Degree of Protection IP20
Depth 9.5 mm
Height 53.3 mm
Humidity 5-95%
Material ABS, Black EDM
Modes of Protection Transverse and Common Modes
Mounting Type KRONE LSA-PLUS
Operational Temperature -40 to 85 deg C
Rated Current 10 kA
Rated Voltage 200 VDC
Resistance 2.7 Ohm
Response Time <5 ns
Standards and Approvals IEC 61643-21:2012, AS/NZS 1768:2007, UL 1449 3rd edition and UL 497B, ITU-T K.44: 2012, AS/CA S008:2010, AS/NZS 4117:1999
Weight 6.5 g
Width 21 mm
