ABB LS33M92B11 Limit Switch Multidirectional Stainless Steel Spring W/Rigid End 1NO-1NC 30mm W Metal

Product Code: LS33M92B11

  • Rated for multiple currents: 3.1A, 10A, 5.5A, 3A
  • IP66 protection for harsh environments
  • Durable metal housing ensures longevity
  • Operates in temperatures from -25°C to 70°C
  • CE and UL approved for safety compliance
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Limit Switch
Brand ABB
Actuator Material Stainless Steel
Actuator Type Multidirectional Spring With Rigid End
Contact Configuration 1NO+1NC
Degree of Protection IP66
Height 174 mm
Housing Material Metal
Length 33 mm
Mechanical Durability >5000000 Operations
Mounting Type 30 mm EN 50047
Operational Temperature -25 to 70 deg C
Rated Current 3.1 A, 10 A, 5.5 A, 3 A
Standards and Approvals CE,UL
Switching Type Snap Action
Weight 0.171 kg
Width 30 mm
