Novaris IS-LCP-18 Load Cell Protector 0.25kA 18VDC 116mm W 56mm D 65mm H Aluminium IP65

Product Code: IS-LCP-18

Surge protector for 18 VDC systems
IP65-rated for robust protection
Operates in -40 to 85°C environments
Aluminium construction, weighs 600 g
Protects with transverse & common modes

Specifications

Product Type	Load Cell Protector
Brand	NOVARIS
Degree of Protection	IP65
Depth	56 mm
Height	65 mm
Humidity	5-95%
Material	Aluminium
Modes of Protection	Transverse and Common Modes
Number of Lines	4, 6
Operational Temperature	-40 to 85 deg C
Rated Current	0.25 kA
Rated Voltage	18 VDC
Tightening Torque	0.5 N-m
Voltage Protection Level	<40 V
Weight	600 g
Width	116 mm

Documents

IPD Product Catalogue

IPD Product Catalogue V17
