Product Code: 942 094-999-001

Explore the Hirschmann RSPS20, a robust Smart Managed Industrial Rail Switch designed for complex network solutions. This switch features 2 SFP slots with a speed of 100 Mbit/s and 4 RJ45 twisted pair ports supporting 10/100 Mbit/s, ensuring versatile connectivity options. Engineered to withstand harsh environments, it operates reliably between 0°C to +60°C and is powered by a wide range of input voltages from 88 to 320 V DC or 88 to 265 V AC. With an IP30 rating and DIN Rail mounting capability, the RSPS20 series switch is an ideal choice for industrial settings requiring durable and secure network management.

Brand	HIRSCHMANN
Maximum Temperature (°C)	60
Minimum Temperature (°C)	0
No. of 100Mb Ports	6
No. of Ethernet Ports	4
No. of Fiber Ports	2
Nominal Power (W)	10
Rated Maximum Operational Voltage AC (V)	265
Rated Maximum Operational Voltage DC (V)	320
Rated Minimum Operational Voltage AC (V)	88
Rated Minimum Operational Voltage DC (V)	88
Degree of Protection	IP30
Mounting Type	DIN Rail
Series	RSPS20

Ethernet Switches

HIRSCHMANN RSPS20-06 00 2Z6 YT-SM9Z9HSE2SXX.X. MANAGED SWITCH 942 094-999-001

Product Code: 942 094-999-001
