Hirschmann 942 170-999-032 Managed Fast Ethernet Switch 8 x 10/100 Base-TX RJ45 -Port (2) 12-24VDC

Product Code: 942 170-999-032

  • Managed switch with 8 ports
  • Supports 12-24 VDC input
  • Compact DIN rail mount design
  • IP30 protection rating
  • CE, FCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Managed Fast Ethernet Switch
Brand HIRSCHMANN
Degree of Protection IP30
Depth 115 mm
Height 138 mm
Mounting Type DIN Rail
Number of Ethernet Ports 8
Number of Ports 8 x 10/100 Base-TX RJ-45
Operational Temperature 0 to 60 deg C
Rated Voltage (2) 12-24 VDC
Standards and Approvals CE, FCC, EN61131, EN62368-1
Switch Type Switch - Managed
Width 73 mm

Description

<p>For professionals in the industrial and commercial sectors, selecting the right managed switch is a critical decision that impacts network efficiency and reliability. This particular managed switch offers robust features designed to meet demanding technical requirements.</p><p>One of its standout features is its dual-rated voltage capability, supporting both 12 VDC and 24 VDC power inputs. This flexibility ensures compatibility with various power systems, providing peace of mind during integration into existing infrastructure.</p><p>Installation is straightforward with DIN rail mounting, a standard in industrial environments for ease of use and secure placement. Its compact dimensions—73 mm wide, 138 mm high, and 115 mm deep—allow it to fit seamlessly into space-constrained setups without compromising on performance or accessibility.</p><p>The device boasts an IP30 degree of protection, making it suitable for indoor applications where exposure to dust or moisture is minimal. It operates efficiently within a temperature range of 0 to 60 degrees Celsius, ensuring reliable performance even in fluctuating environmental conditions typical of industrial settings.</p><p>This managed switch supports eight ports with 10/100 Base-TX RJ-45 connections. These ports are ideal for creating a stable local area network (LAN), facilitating smooth data transfer across connected devices. The management capabilities allow for advanced configuration options tailored to specific network needs, enhancing control over traffic flow and security measures.</p><p>Compliance with international standards such as CE, FCC, EN61131, and EN62368-1 underscores the product&amp;#39;s quality assurance and safety credentials. These certifications indicate adherence to rigorous testing protocols that ensure the device performs reliably under specified conditions while meeting global industry benchmarks.</p><p>In summary, this managed switch combines versatility with robust design elements suited for industrial applications. Its compliance with key standards further reinforces its reliability as a choice for professionals seeking dependable network solutions in their operations.</p>
