Products

HIRSCHMANN MANAGED GIGABIT ETHERNET SWITCH 942 170-999-008

Product Code: 942 170-999-008

  • Managed Industrial Switch Fast Ethernet Type 8x 10/100BASE-TX RJ45 ports Power input range: 12 VDC to 24 VDC Power consumption: 6 W Operating temperature range: 0 °C to +60 °C IP30 protection rating DIN Rail mounting option BOBCAT Series by Hirschmann
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Type DIN Rail
Maximum Temperature (°C) 70
Minimum Temperature (°C) -40
Operational Temperature Range (°C) -40 to +70
Brand HIRSCHMANN
Product Type Managed
Series BOBCAT
No. of 1GB Ports 12
No. of Ethernet Ports 8
No. of Fiber Ports 4
No. of Ports 8 x 10/100/1000BASE-TX RJ45, 4 x 100/1000 Fiber SFP
Nominal Power (W) 11
Power Consumption (W) 11
Rated Maximum Operational Voltage DC (V) 24
Rated Minimum Operational Voltage DC (V) 12
Rated Operational Voltage DC (V) 2 x 12 - 24
Switch Type Switch - Managed
Dimensions (mm) 138H x 73W x 115D
Degree of Protection IP30
Standards and Approvals CE, FCC, EN61131, EN62368-1

Description

Explore the Hirschmann BOBCAT Series Managed Industrial Switch, a robust networking solution designed for demanding environments. This all-Gigabit switch features 12 ports, including 8 RJ45 ports supporting 10/100/1000BASE-TX and 4 fiber ports with 100/1000Mbit/s capability. It offers dual uplink connectivity with 4 SFP slots for 100/1000 Mbit/s, ensuring high-speed data transmission and redundancy. The switch operates on a dual power input of 12 VDC to 24 VDC and maintains energy efficiency with an 11 W power consumption. Engineered to withstand extreme temperatures ranging from -40 to +70°C and certified with an IP30 rating, it's ideal for industrial applications requiring durability and reliability. Installation is made easy with DIN Rail mounting, making the Hirschmann BOBCAT Series the go-to choice for advanced network solutions in challenging industrial settings.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
