Specifications

Dimensions (mm)	27W x 95H x 82.5D
No. of Poles	1
Rated Current (A)	100
Rated Frequency (Hz)	50
Rated Impulse Withstand Voltage (kV)	8
Voltage Type	DC
Maximum Breaking Capacity	(250 V DC) 50 kA
Product Type	MCB
Brand	ABB
Series	S800HV
Curve Type	UC-K
Degree of Protection	IP20
Standards and Approvals	IEC/EN 60947-2
