ABB SH201C8 Miniature Circuit Breaker 6kA 1-P 8A 230V C-Curve

Product Code: SH201C8

  • 8 A rated current with 6 kA breaking capacity
  • Compact size: 17.5 mm wide, fits DIN rail
  • Operates in -25 to 55°C, stores at -40 to 70°C
  • Screw clamp terminals with 2 N-m torque
  • Complies with IEC/EN 60898-1 standards
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 17.5W x 85H x 69D
No. of Poles 1P
Power Loss (W) 1.5
Pollution Degree 2
Rated Current (A) 8
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) 440
Rated Impulse Withstand Voltage (kV) 4
Weight (kg) 0.125
Rated Operational Voltage (V) 230
Family SH200
Icn-Rated Short Circuit Capacity (kA) 6
Inc-Rated Conditional Short Circuit Capacity (kA) 6
Product Type Miniature Circuit Breaker
Brand ABB
Actuator Type Toggle
Ambient Temperature -25 to 55 deg C Operation, -40 to 70 deg C Storage
Breaking Capacity 6 kA
Collection SH200
Curve Type C
Degree of Pollution IP2
Degree of Protection IP20
Depth 69 mm
Electrical Durability 20000 Cycles
Height 85 mm
Housing Colour RAL 7035 Grey
Mounting Type DIN Rail
Number of Poles 1
Power Loss 1.5 W
Rated Current 8 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 440 V
Rated Voltage 230 V
Standards and Approvals IEC/EN 60898-1
Terminal Type Screw Clamp
Tightening Torque 2 N-m
Trip Curve C Curve
Weight 0.125 kg
Width 17.5 mm
