Specifications

Dimensions (mm)	27W x 142H x 82.5D
No. of Poles	1
Rated Current (A)	63
Rated Frequency (Hz)	50
Rated Impulse Withstand Voltage (kV)	8
Voltage Type	AC
Maximum Breaking Capacity	4kA at 580/1000V
Product Type	MCB
Brand	ABB
Series	S800HV
Curve Type	K
Degree of Protection	IP20
Housing Material	Insulation group I, RAL 7035
Mounting Type	DIN Rail
Standards and Approvals	IEC/EN 60947-2 UL 1077
