When selecting a circuit breaker for your industrial or commercial application, it's essential to consider the technical specifications that will ensure reliability and safety. This single-pole circuit breaker is engineered to provide robust protection with its comprehensive features.
With a rated current of 6 A, this breaker is designed for systems operating at 230/400 VAC. Its rated insulation voltage stands at 440 V, offering reliable isolation in electrical circuits. The device's rated impulse withstand voltage of 4 kV indicates its capability to handle transient overvoltages effectively.
This unit has an impressive breaking capacity of 11.3 kA, ensuring it can interrupt fault currents without damage. Additionally, it boasts a short circuit capacity of 15 kA, which speaks to its resilience under extreme conditions.
The construction adheres to IEC/EN 60898-1 and IEC/EN 60947-2 standards, providing assurance of international compliance and quality. It operates efficiently across a frequency range of 50/60 Hz and is built for durability with an electrical lifespan extending up to 20,000 cycles.
Designed for ease of installation on DIN rails, this circuit breaker features screw clamp terminals requiring a tightening torque of 2.8 N-m. The compact dimensions—17.5 mm in width, 88 mm in height, and a depth of 69 mm—make it suitable for space-constrained panels.
In terms of environmental performance, the device operates reliably within ambient temperatures ranging from -25°C to +55°C and can be stored safely between -40°C and +70°C. Its degree of protection is IP20 while maintaining an IP3 degree of pollution rating.
The housing comes in RAL 7035 grey—a standard color that blends well with most industrial environments. The curve type C characteristic ensures suitable tripping behavior under overload conditions typical in commercial applications.
Overall, this product offers dependable performance backed by rigorous standards compliance making it ideal for professionals seeking efficiency and safety in their electrical installations.
