Specifications

Dimensions (mm)	54W x 95H x 82.5D
No. of Modules	3
No. of Poles	2
Operational Temperature Range (°C)	-25 to 60 °C
Power Loss (W)	8.3W per Pole
Rated Current (A)	100
Rated Impulse Withstand Voltage (kV)	8
Weight (kg)	0.49
Rated Operational Voltage (V)	500V DC
Product Type	MCB
Brand	ABB
Curve Type	UC-K
Degree of Protection	IP20
Mounting Type	DIN-Rail
Standards and Approvals	IEC/EN 60947-2
