ABB S202MT-Z16 Miniature Circuit Breaker 11.3kA 2-P 16A 400V Z-Curve

Product Code: S202MT-Z16

  • Rated current of 16 A for reliable performance
  • Breaking capacity of 11.3 kA ensures safety
  • IP20 protection against solid objects
  • Compact design: 35 mm wide, 88 mm high, 69 mm deep
  • Operates in -25 to 55°C; stores at -40 to 70°C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Miniature Circuit Breaker
Brand ABB
Ambient Temperature -25 to 55 deg C Operation, -40 to 70 deg C Storage
Breaking Capacity 11.3 kA
Curve Type Z
Degree of Pollution IP3
Degree of Protection IP20
Depth 69 mm
Height 88 mm
Housing Colour RAL 7035 Grey
Number of Poles 2
Power Loss 6.2 W
Rated Current 16 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 440 V
Rated Short Circuit Current 15 kA
Rated Voltage 400 V
Standards and Approvals IEC/EN 60947-2
Terminal Type Screw Clamp
Tightening Torque 2.8 N-m
Width 35 mm
