When considering a reliable and robust Miniature Circuit Breaker (MCB) for your commercial or industrial applications, the S200M series stands out as a dependable choice. Engineered to meet rigorous standards, this MCB ensures safety and efficiency in electrical systems.
Operating within a rated current of 0.5 A, it is designed to handle demanding environments with precision. The breaker accommodates voltages up to 400/415 VAC and boasts an impressive breaking capacity of 15 kA at 400 VAC, making it suitable for various power distribution needs.
One of its key features is the rated impulse withstand voltage of 4 kV and insulation voltage of 440 V, which together provide excellent protection against overvoltage conditions. The device's electrical durability is notable, enduring up to 20,000 cycles—an assurance of long-lasting performance.
The S200M MCB offers a degree of protection classified as IP20, ensuring that it can withstand accidental contact with fingers or similar objects while maintaining operational integrity in typical industrial settings. With dimensions measuring a width of 52.5 mm, height of 88 mm, and depth of 69 mm, it's compact enough for easy integration into existing systems via DIN rail mounting.
Designed with user convenience in mind, the screw clamp terminal type allows secure connections with a tightening torque specification set at 2.8 N-m. This feature supports cable cross sections up to 35 sq-mm on both top and bottom terminals while accommodating bulbar cross sections up to 10 sq-mm—a testament to its versatility in installation scenarios.
The MCB operates efficiently across temperatures ranging from -25°C to +55°C during operation and can be stored safely between -40°C and +70°C without compromising functionality—ideal for diverse Australian climates.
Its curve type C characteristic makes it suitable for protecting circuits with moderate levels of inductive loads where short circuit capacity reaches up to an impressive rating of either 10 kA or even higher at specific fault conditions like rated short circuit current at an astonishing rate of up to 25 kA.
Compliant with AS/NZS standards such as AS/NZS 60898-1 and AS/NZS60947-2 alongside UL1077 approval indicates adherence not only locally but also internationally recognized benchmarks ensuring quality assurance wherever deployed globally including within Australia’s stringent regulatory landscape requirements too!
In terms of aesthetics yet functional design aspects: housed attractively finished RAL7035 grey colour casing blends seamlessly into modern control panels providing professional look whilst maintaining practical usability throughout lifespan usage expected from any high-end product offering today’s market demands alike!
