ABB S203MT-K25 Miniature Circuit Breaker 11.3kA 3-P 25A 400V K-Curve

Product Code: S203MT-K25

  • Rated for 25 A, suitable for various applications
  • High breaking capacity of 11.3 kA
  • Compact design: 52.5mm (W) x 88mm (H) x 69mm (D)
  • Operates in temps from -25°C to 55°C
  • IP20 protection with screw clamp terminals
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Miniature Circuit Breaker
Brand ABB
Ambient Temperature -25 to 55 deg C Operation, -40 to 70 deg C Storage
Breaking Capacity 11.3 kA
Curve Type K
Degree of Protection IP20
Depth 69 mm
Height 88 mm
Housing Colour RAL 7035 Grey
Number of Poles 3
Power Loss 9.3 W
Rated Current 25 A
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 440 V
Rated Voltage 400 V
Standards and Approvals IEC/EN 60947-2
Terminal Type Screw Clamp
Tightening Torque 2.8 N-m
Width 52.5 mm
