The MCCB (Molded Case Circuit Breaker) is a robust and reliable choice for industrial and commercial applications, designed to meet the demanding needs of electrical distribution systems. With a rated current of 63 A, this MCCB ensures efficient protection against overloads and short circuits, making it an essential component for maintaining system integrity.
Engineered with a rated impulse withstand voltage of 8 kV and a rated insulation voltage of 1000 V, this circuit breaker provides exceptional durability in high-voltage environments. It operates effectively at a rated voltage of 690 VAC/VDC, offering flexibility for various power systems.
The trip unit equipped with this MCCB is the Ekip Dip LSI type, known for its precision in fault detection and rapid response times. This ensures minimal downtime during fault conditions while safeguarding connected equipment. The release type EL further enhances its reliability by providing consistent performance across different operational scenarios.
With a breaking capacity of 12 kA, the MCCB can handle substantial fault currents without compromising safety or functionality. Its three-pole configuration allows for balanced protection across multiple phases, which is crucial in complex electrical setups.
Installation is straightforward thanks to its front connection type and bolt terminal design. These features simplify wiring tasks while ensuring secure connections that withstand mechanical stresses over time. Additionally, the device's width is compact at 90 mm, allowing it to fit easily into standard panels without requiring excessive space.
The degree of protection offered by this MCCB is IP20, which means it has adequate protection against solid objects larger than 12 mm but should be housed appropriately if environmental factors are a concern. Weighing just 1.2 kg, it's lightweight yet sturdy enough to endure typical industrial conditions.
This product adheres to IEC60947-2 standards and approvals, underscoring its compliance with international safety and performance benchmarks—a critical factor when selecting components for sensitive installations.
Designed to operate efficiently within frequencies ranging from 50/60 Hz, it seamlessly integrates into existing systems without necessitating additional modifications or adjustments. The main circuit connecting capacity ranges from 32.5-100 sq-mm ensuring compatibility with various conductor sizes used in modern installations.
Moreover, it's suitable for use with XT2S configurations enhancing its versatility across different setups—whether you're upgrading existing systems or implementing new ones entirely.
In summary, this MCCB offers dependable performance backed by rigorous standards compliance making it an excellent choice for professionals seeking reliable circuit protection solutions tailored specifically towards industrial settings where precision matters most.
