When it comes to choosing a reliable Molded Case Circuit Breaker (MCCB) for your industrial or commercial applications, the specifications and performance metrics are what truly matter. This MCCB stands out with its robust design and technical features that cater to demanding environments.
Rated at 160 A, this MCCB is built to handle significant electrical loads while maintaining safety and efficiency. It boasts a Rated Impulse Withstand Voltage of 8 kV and a Rated Insulation Voltage of 800 V, ensuring resilience against voltage spikes and insulation breakdowns. The device supports both AC and DC circuits with a Rated Voltage of up to 690/500 VAC/VDC, making it versatile for various applications.
The Thermal Magnetic (TM) release type paired with a Thermal Magnetic Trip Unit (TMD) provides dependable protection by automatically disconnecting the circuit during overloads or short circuits. With a Breaking Capacity of 50 kA, this MCCB is equipped to interrupt high fault currents effectively, safeguarding your equipment from potential damage.
Designed with practicality in mind, the MCCB features four poles and offers front connection type for ease of installation. The bolt terminal type further enhances secure connections. Despite its powerful capabilities, it maintains an IP20 degree of protection which suits indoor environments where dust protection is required but not water ingress.
In terms of dimensions, the MCCB has a width of 140 mm which allows it to fit comfortably within standard panel spaces without compromising on performance. Weighing in at just 2.1 kg, it's lightweight enough for easy handling yet sturdy enough to endure rigorous use.
Compliant with IEC60947-2 standards and approvals, this product meets international benchmarks for quality and safety—providing peace of mind in critical operations. Operating efficiently across frequencies of 50/60 Hz ensures compatibility with global power systems.
This MCCB also offers an adjustable Current Setting Range between 112-160 A allowing flexibility according to specific load requirements—a feature particularly beneficial when dealing with variable operational conditions. Its Main Circuit Connecting Capacity ranges from 85-192 sq-mm accommodating different conductor sizes seamlessly.
Built specifically for use alongside products like the XT3S series—this compatibility ensures smooth integration into existing setups without extensive modifications needed.
Overall power loss is kept minimal at just 7.9 W contributing towards energy efficiency goals while maintaining optimal functionality throughout its lifecycle—a crucial factor when considering long-term operational costs versus benefits analysis within any project scope involving electrical distribution components such as these mid-cycle solutions tailored towards discerning professionals seeking factual evidence over emotional appeal when making purchasing decisions based upon technical merit alone.
