The MCCB you're considering offers a reliable solution for industrial and commercial electrical systems. Designed to handle demanding environments, this molded case circuit breaker (MCCB) is engineered with precision to meet various technical requirements.
With a rated current of 160 A, it provides robust performance, ensuring your electrical systems operate efficiently. It boasts a high rated impulse withstand voltage of 8 kV and an impressive rated insulation voltage of 1000 V, making it suitable for applications requiring resilience against voltage surges.
This MCCB operates at a rated voltage of 690 VAC and accommodates both 50 Hz and 60 Hz frequency systems, providing versatility across different setups. The Ekip Dip LSI trip unit ensures accurate protection through its electronic release type (EL), offering precise control over the circuit breaker's operation.
When it comes to safety and reliability, this MCCB doesn't fall short. It features a breaking capacity of 12 kA, allowing it to effectively interrupt fault currents without compromising system integrity. Additionally, the degree of protection is rated at IP20, safeguarding internal components from dust ingress while maintaining user safety.
Installation is straightforward with its front connection type and bolt terminal configuration. This design simplifies integration into existing panels or new installations alike. With dimensions measuring just 140 mm in width and weighing in at only 3.5 kg, it's both compact and lightweight—ideal for space-constrained environments.
The main circuit connecting capacity ranges from 85-200 sq-mm, accommodating various cable sizes for flexible installation options. Furthermore, this MCCB adheres to IEC60947-2 standards and approvals, ensuring compliance with international regulations for peace of mind regarding quality and performance.
Designed specifically for use with XT4S models, this product integrates seamlessly into compatible systems without hassle. Its power loss stands at an efficient 8.9 W during operation—an important consideration when evaluating energy consumption within your facility's infrastructure.
In summary, this MCCB offers comprehensive features tailored towards enhancing operational efficiency while prioritizing safety standards essential in industrial settings today—all backed by rigorous adherence to industry norms like IEC60947-2 certification—making it an excellent choice if these specifications align perfectly within your project scope!
