When it comes to safeguarding your electrical systems, choosing the right surge protector is crucial. This surge protector offers robust protection for industrial and commercial applications, ensuring the safety and longevity of your equipment. With a rated voltage of 200 VDC and a substantial rated current capacity of 20 kA, this device is engineered to handle significant power surges effectively.
The product's degree of protection is classified as IP20, making it suitable for indoor environments where dust ingress needs to be minimized but water resistance isn't required. Its panel mounting type ensures easy integration into existing setups without requiring extensive modifications. The compact dimensions—128 mm in width, 80 mm in height, and 42 mm in depth—allow for efficient use of space while maintaining accessibility for maintenance or inspection.
Designed to operate across a wide temperature range from -40°C to 85°C, this surge protector can withstand harsh environmental conditions without compromising performance. It adheres to multiple standards and approvals such as IEC61643-21, ITU-T K.44, AS/NZS 1768, IEEE C62.41, and UL497B, providing assurance that it meets rigorous international safety and performance criteria.
Weighing in at just 250 grams, it's lightweight yet sturdy enough for demanding applications. The unit supports operational humidity levels ranging from 5% to 95%, offering flexibility in various climatic conditions without risk of condensation affecting its functionality.
For secure installation, the recommended tightening torque is set at 0.5 N-m. The device features a resistance level of 8.2 Ohm which aids in managing energy dissipation during surges efficiently.
This surge protector provides both transverse and common modes of protection across its twelve lines—a feature particularly advantageous when dealing with complex electrical systems that require comprehensive coverage against transient voltages.
Finally, it boasts a rated short circuit current capability of up to 2 A—ensuring that even under fault conditions the system remains protected while minimizing downtime due to unexpected power issues.
Overall this surge protector represents a reliable choice for those looking to enhance their system's resilience against voltage spikes with confidence backed by compliance with established industry standards.
