Specifications

Dimensions (mm)	48W x 44D
Reference No.	392069
Thickness (mm)	3/2.5
Suitable For	Air-termination rods and round conductors
Weight (kg)	0.126
Class (Lightning Current Carrying Capability) (kA)	100/50
Surface Protection	Untreated
Conductor Diameter (mm)	8
Lightning current load-bearing capacity (10/350µs)	100
Clamping Range Rd/Rd (mm)	8 - 10 / 16
Type	Equipotential Bonding
Product Type	MV Clamp
Brand	DEHN
Clamping Range	8-10 mm, 16 mm
Conductor Size	8 mm
Connection Type	M10 x 40 mm Screw
Connector Type	T/Cross/Parallel Connector
Depth	44 mm
Finish	Untreated
Lid Screw Type	Truss Head Screw
Lightning Current Carrying Capability	50 kA, 100 kA
Material	Stainless Steel
Screw Size	M10 x 40mm
Standards and Approvals	EN 62561-1
Suitable For Use With	Air Termination Rods and Round Conductors
Thickness	3 mm, 2.5 mm
Weight	0.126 kg
Width	48 mm
