IDECYW4B-M1E10B Non-Illuminated Pushbutton 22mm Flush Momentary Black 1NO

Product Code: YW4B-M1E10B

  • Non-illuminated flush actuator design
  • IP65 front protection rating
  • Mechanical life up to 5 million ops
  • Rated insulation voltage of 600 V
  • Metal bezel for durability
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Flush
Bezel Material Metal
Button Colour Black
Colour Black
Contact Configuration 1NO
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Flush - Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4B-M1E10B is a non-illuminated, black flush momentary pushbutton designed for efficient use of space with its 10mm thick contact blocks. This compact and lightweight switch features a removable operator and a durable metal bezel. The design includes unibody pilot lights and key selector switches for additional functionality. Its separate contact block simplifies installation and maintenance procedures.
