IDECYW1B-M1E10W Non-Illuminated Pushbutton 22mm Flush Momentary White 1NO

Product Code: YW1B-M1E10W

  • Non-illuminated flush pushbutton, white
  • IP65 front protection for durability
  • Screw terminal connections
  • Mechanical life up to 5M operations
  • CE, cULus, UKCA, CCC certified
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Contacts 1NO
Conventional Free-Air Thermal Current - Ith (A) Contact Rating - 10
Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Insulation Voltage (V) Contact Rating - 600
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Flush
Bezel Material Plastic
Bezel Type Plastic
Button Colour White
Colour White
Contact Configuration 1NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 56.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Mode of Operation Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Terminal Type Screw
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW1B-M1E10W is a non-illuminated, momentary pushbutton with a sleek white flush design and one normally open (NO) contact. It is engineered for 22mm mounting and offers an IP20 rating, ensuring protection against solid objects. For enhanced safety, it comes with finger-safe terminals. This pushbutton is ideal for applications requiring a reliable and secure momentary switching solution.
