IDECHW1B-M1F20-S Non-Illuminated Pushbutton 22mm Flush Momentary Blue 2NO

Product Code: HW1B-M1F20-S

  • Non-illuminated, flush actuator design
  • IP65 front protection for durability
  • Screw terminals for secure connections
  • 2NO contact configuration with silver contacts
  • Operates in -25 to 60°C temperature range
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Flush
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Blue
Colour Blue
Contact Configuration 2NO
Contact Material Silver
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 22 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M1F20-S is a robust pushbutton featuring a blue 29mm mushroom head for quick and easy actuation. Its momentary operation ensures the button returns to its original position after being pressed, suitable for commands that require brief engagement. The durable plastic bezel provides resilience in various industrial environments. This pushbutton is part of the HW series, designed for reliability and ease of use in control applications.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
