IDECHW1B-M3F20-S Non-Illuminated Pushbutton 29mm Mushroom Momentary Blue 2NO

Product Code: HW1B-M3F20-S

  • Non-illuminated, momentary mushroom actuator
  • IP65 front protection for harsh environments
  • Screw terminals for secure connections
  • 29mm cutout with round plastic bezel
  • Rated insulation voltage of 600V
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Mushroom
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Blue
Colour Blue
Contact Configuration 2NO
Contact Material Silver
Cutout Size 29 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 29 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M3F20-S is a robust pushbutton featuring a 29mm blue mushroom head for quick and easy actuation. Its momentary action ensures the button returns to its original position after activation, suitable for critical operations. The durable plastic bezel provides resilience in industrial environments. This pushbutton is part of the HW series, designed for reliability and ease of use in various applications.
