IDECHW1B-M3F20-Y Non-Illuminated Pushbutton 29mm Mushroom Momentary Yellow 2NO

Product Code: HW1B-M3F20-Y

  • Non-illuminated yellow mushroom actuator
  • IP65 front protection for durability
  • Screw terminals for secure connections
  • Rated insulation voltage of 600 V
  • Momentary function with 2NO contacts
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 2
Terminal Shape Screw terminal
Product Type Pushbutton
Brand IDEC
Series HW
Actuator Type Mushroom
Bezel Colour Black
Bezel Material Plastic
Bezel Shape Round
Button Colour Yellow
Colour Yellow
Contact Configuration 2NO
Contact Material Silver
Cutout Size 29 mm
Degree of Protection IP65 Front, IP20 Terminal
Diameter 29 mm
Function Momentary
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Operational Temperature -25 to 60 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Terminal Type Screw

Description

The IDEC HW1B-M3F20-Y is a robust 29mm yellow mushroom pushbutton designed for momentary action. This non-illuminated switch features a durable plastic bezel and two normally open (2NO) contacts. Engineered for 22mm mounting, it's part of the HW series, offering reliable performance in various industrial applications. Its extended design ensures easy accessibility and operation within control systems.
