IDEC YW1P-1BUQ3Y Pilot Light With LED Yellow 12VDC 22mm Dia Mount Hole

Product Code: YW1P-1BUQ3Y

  • IP66 rating for robust protection
  • Momentary actuation for quick signaling
  • 1NO+1NC contact configuration
  • Modular plastic bezel for durability
  • Fits standard 22 mm cutouts
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 12
Insulation Resistance (MO) 100
Product Type Pilot Light With LED
Brand IDEC
Series YW
Actuation Type Momentary
Bezel Material Modular Plastic
Contact Configuration 1NO+1NC
Cutout Size 22 mm
Degree of Protection IP66
Lamp Type Built-in LED
LED Colour Yellow
Number of Positions 4
Terminal Type Screw (M3.5)

Description

The IDEC YW1P-1BUQ3Y Unibody Pilot Light is a robust signaling device with a yellow LED for clear visibility. It operates on a 12VAC/DC power supply and is designed for flush mounting with a 22mm diameter. The pilot light's compact size allows for easy integration into diverse applications, while its IP20 finger safe terminals provide enhanced safety during use.
