Panasonic EX-11EB-PN Ultra-slim Photoelectric Sensor 12-24VDC 150mm Sensing 2m L Cable PNP-Output

Product Code: EX-11EB-PN

  • Sensing range up to 150 mm
  • Operates on 12-24 VDC with <10 mA current
  • Durable polyarylate housing, IP67 rated
  • Fast response time under 0.5 ms
  • Clear orange LED operation indicator
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Ultra-slim Photoelectric Sensor
Brand PANASONIC
Cable Length 2 m
Cable Type 2 core cabtyre
Degree of Protection IP67
Housing Material Polyarylate
Humidity 35-85%
Illuminance 3000 lx
Insulation Resistance 20 MOhm
Operation Indicator Orange LED ON
Operational Temperature -30 to 70 deg C
Output Type PNP
Rated Current <10 mA
Rated Voltage 12-24 VDC
Relative Humidity 35 to 85%
Response Time <0.5 ms
Sensing Range 150 mm
Sensor Type Standard Thru-Beam Side Sensing
Shock Resistance 500 ms
Utilisation Category DC-12 or DC-13
Weight 50 g

Description

<p>When it comes to reliable and precise object detection, this Photoelectric Sensor stands out as a dependable choice for industrial and commercial applications. Designed to meet the demands of various environments, this sensor combines robust construction with efficient performance, making it an ideal solution for your sensing needs.</p><p>The sensor offers a sensing range of up to 150 mm, providing adequate coverage for most standard applications. It operates on a rated voltage between 12-24 VDC while maintaining a low current consumption of less than 10 mA. This efficiency ensures that the sensor is both cost-effective and energy-saving over time.</p><p>With its PNP output type, the sensor is compatible with numerous control systems, offering versatility in integration. The housing material is made from polyarylate, known for its durability and resistance to harsh conditions. Its IP67 protection rating further guarantees that the device can withstand dust ingress and temporary immersion in water, making it suitable for challenging industrial settings.</p><p>Operating within a humidity range of 35-85% and an operational temperature span from -30 to 70 degrees Celsius, this photoelectric sensor adapts well to varying environmental conditions without compromising performance. Weighing just 50 grams, it is lightweight yet sturdy enough to endure demanding tasks.</p><p>The shock resistance capability at 500 ms ensures resilience against mechanical impacts or vibrations commonly encountered in industrial environments. Additionally, the insulation resistance of 20 MOhm provides enhanced safety by minimizing electrical leakage risks.</p><p>One key feature is its rapid response time of less than 0.5 ms which allows for quick detection and processing—crucial in high-speed operations where timing precision matters. The included cable length of 2 meters facilitates easy installation across different setups without requiring additional extensions.</p><p>This sensor also features an orange LED operation indicator that lights up when active—providing clear visual confirmation that helps technicians quickly assess operational status during maintenance checks or troubleshooting sessions.</p><p>Overall, this photoelectric sensor delivers consistent performance with minimal maintenance requirements—a practical choice engineered for those seeking reliability along with straightforward functionality in their automation processes.</p>

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
