IDECYW4B-M1E10G Non-Illuminated Pushbutton 22mm Flush Momentary Green 1NO

Product Code: YW4B-M1E10G

  • Non-illuminated flush actuator, momentary function
  • IP65 front protection, robust metal bezel
  • High mechanical life: 5M single, 1M double ops
  • cULus listed, CE marked for compliance
  • Operates in -20 to 55°C; stores at -40 to 85°C
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

No. of Normally-open Contacts 1
Product Type Pushbutton
Brand IDEC
Series YW
Actuator Type Flush
Bezel Material Metal
Button Colour Green
Colour Green
Contact Configuration 1NO
Cutout Size 22 mm
Degree of Protection IP65 Front, IP20 Terminal
Depth 64.8 mm
Diameter 22 mm
Function Momentary
Height 41.4 mm
Humidity 45-85%
Illumination Non-Illuminated
Insulation Resistance 100 MOhm
Mechanical Life 5 million Operations Single Contact Block, 1 million Operations Double Contact Block
Model Flush - Momentary
Operational Temperature -20 to 55 deg C
Rated Continuous Current 10 A
Rated Insulation Voltage 600 V
Shock Resistance 10 g/ms
Standards and Approvals cULus listed, CE Marked, UKCA Certified, CCC Certified
Storage Temperature -40 to 85 deg C
Vibration Resistance 5-55 Hz
Width 30 mm

Description

The IDEC YW4B-M1E10G is a momentary pushbutton featuring a flush metal bezel designed for efficient use of space with its 10mm thick contact blocks. The compact and lightweight design includes a removable operator for flexibility. Enhanced with unibody pilot lights and key selector switches, this pushbutton ensures ease of installation and maintenance due to its separate contact block. Ideal for streamlined control panel setups, it offers both aesthetic appeal and functional efficiency.
