The YW Series Pushbutton is a reliable choice for industrial and commercial applications, designed with precision to meet high standards of performance and durability. This non-illuminated pushbutton features a flush actuator type, offering a sleek appearance with its vibrant red button color. Its compact dimensions include a width of 30 mm, height of 41.4 mm, and depth of 64.8 mm, making it suitable for installations where space is a consideration.
Engineered to withstand challenging environmental conditions, the pushbutton operates effectively within temperatures ranging from -20 to 55 degrees Celsius and can be stored in temperatures as low as -40 degrees Celsius up to 85 degrees Celsius. The device maintains optimal functionality in humidity levels between 45% and 85%, ensuring reliability even in varying climates.
The YW Series Pushbutton offers robust protection with an IP65 rating at the front, safeguarding against dust ingress and water jets from any direction. Meanwhile, the terminal achieves an IP20 rating for basic touch protection. These ratings make it ideal for use in environments where exposure to moisture or dust is common.
Built to last, this pushbutton boasts impressive mechanical life spans: up to five million operations for single contact blocks and one million operations for double contact blocks. The device's vibration resistance ranges from 5-55 Hz while its shock resistance stands at 10 g/ms—attributes that contribute significantly to its durability under demanding conditions.
With a rated insulation voltage of 600 V and an insulation resistance exceeding 100 MOhm, safety is paramount in this design. The contact configuration includes two normally open (2NO) contacts capable of handling continuous currents up to 10 A efficiently.
Compliant with multiple international standards such as cULus listing, CE marking, UKCA certification, and CCC certification ensures that this pushbutton meets rigorous quality requirements globally. Additionally, it features a metal bezel material which adds strength while maintaining aesthetic appeal.
For installation ease, the cutout size required matches its diameter at precisely 22 mm—a standard size that fits seamlessly into many existing panels or enclosures without additional modifications needed.
In summary,the YW Series Pushbutton combines practicality with superior engineering suited perfectly towards industry professionals seeking dependable components tailored specifically around stringent operational demands across diverse settings without compromise on quality assurance measures adhered strictly throughout every stage involved during production processes ensuring peace-of-mind usage aligned closely alongside evolving market expectations consistently over time thereby reinforcing trust placed upon these products repeatedly by discerning clientele worldwide who value excellence above all else when selecting equipment integral towards achieving business objectives successfully long-term amidst ever-changing landscapes encountered daily within respective fields pursued diligently always striving forward positively together collaboratively united through shared goals ultimately benefiting everyone involved collectively overall mutually beneficially so!
