Products

Photovoltaic Isolators & Protection

ADLER FUSE LINK 60A 1500V DC 22X58mm FERRULE TYPE A942600B00

Product Code: A942600B00

The A94 Photovoltaic (PV) fuse link is a high-power solution for PV applications. It has a 22x58 mm size and features a glass-fiber body. The fuse link is designed specifically for gPV 1500 VDC systems. With silver plated caps, it offers enhanced performance and durability.

Technical Specifications

Pack Quantity 20
Brand ADLER
Interrupting Rating (kA) 10
Power Loss (W) 10
Rated Current (A) 60
Rated Voltage DC (V) 1500
Suitable Fuse Holder BH400
Terminal Type Ferrule
Diameter (mm) 22
Time Constant (ms) 1-3
Length (mm) 58

Documents
