IDEC YW1P-2EQ0S Pilot Light Blue 250VAC 29.8 mm Dia Mount Hole

Product Code: YW1P-2EQ0S

  • Compatible with 22 mm pilot devices
  • Reliable and durable design
  • Easy installation and maintenance
  • Enhances visibility in control panels
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 250
Insulation Resistance (MO) 100
Lamp Not Included
Product Type Pilot Light
Brand IDEC
Series YW
Colour Blue
Degree of Protection IP65 (Front), IP20 (Terminals)
Lamp Type Not included
Model Replacement Lamp Type
Suitable For Use With 22 mm Pilot Devices
Terminal Type Screw (M3.5)

Description

The IDEC YW1P-2EQ0S is a blue dome-type Pilot Light Replacement Lamp engineered for minimal heat generation and extended lifespan. It operates at 250VAC/DC and is suitable for 22mm panel cutouts. Safety is enhanced with IP20 finger-safe terminals, ensuring secure operation in various industrial settings.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
