ABB MPLC0 Pilot Light Kit with Integrated LED Clear 12VDC

Product Code: MPLC0

  • Operates at 415 VAC, 50/60 Hz
  • Green LED illumination
  • IP20 protection rating
  • Screw clamp connection
  • Rear mounting design
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Rated Voltage DC (V) 12
LED Block Rated Voltage 12 VDC
Bezel Material Plastic
Product Type Pilot Light Kit
Brand ABB
Colour Green
Connecting Capacity Flexible with Ferrule 1 x 0.75...2.5 sq-mm, Flexible with Ferrule 2 x 0.75...2.5 sq-mm, Flexible with Insulated Ferrule 1 x 0.75...2.5 sq-mm, Flexible with Insulated Ferrule 2 x 0.75...2.5 sq-mm, Flexible 1 x 0.75 ... 2.5 sq-mm, Flexible 2 x 0.75 ... 2.5 sq-mm. Solid 1 x 0.75...2.5 sq-mm. Solid 2 x 0.75...2.5 sq-mm
Connection Type Screw Clamp
Degree of Protection IP20
Illumination Illuminated
Lamp Type Integrated LED
LED Colour Clear
Mounting Type Rear
Rated Frequency 50/60 Hz
Rated Voltage 415 VAC
Terminal Type Screw
Tightening Torque 0.9 N-m
Wire Stripping Length 8 mm

Description

The Pilot Lights kit Clear 12VDC is a part of our modular plastic range. It is designed for engineers and provides clear visibility with its pilot lights. The kit operates on a 12VDC power supply.
