IDEC YW1P-2EM45Y Pilot Light Yellow 22mm Dia Mount Hole

Product Code: YW1P-2EM45Y

  • Compact design: 9.6 mm width, 39.5 mm height
  • Wide temp range: -30 to 70°C operational
  • IP20 protection for secure usage
  • Front mounting for easy installation
  • Rated insulation voltage up to 690 V
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 78.8D
Operating Voltage DC (V) 230/240
Operating Voltage AC (V) 230/240
Product Type Pilot Light
Brand IDEC
Ambient Temperature -30 to 70 deg C
Colour Brown
Connecting Capacity 1/2 x 0.75-2.5 sq-mm Flexible with Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible with Insulated Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible, 1/2 x 0.75-2.5 sq-mm Solid
Contact Configuration 1NO
Degree of Pollution IP3
Degree of Protection IP20
Depth 27.7 mm
Height 39.5 mm
Model Dome Transformer - With Incandescent Lamp
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Impulse Withstand Voltage 4 kV
Rated Insulation Voltage 690 V
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Width 9.6 mm
Wire Stripping Length 10 mm

Description

The IDEC YW1P-2EM45Y is a transformer-type incandescent pilot light designed for efficient operation and easy installation. Its yellow illumination and large lens offer a broad viewing angle, while the space-saving 10mm thick contact blocks ensure a compact footprint. The unit features a durable metal bezel and is both lightweight and unibody in design. For convenience, the separate contact block allows for straightforward installation and removal. This pilot light is part of the YW series, known for its reliable performance in various applications.
