IDEC YW1P-2EQ4A PILOT LIGHT WITH LED REPLACEMENT LAMP AMBER 24VAC/DC 22MM

Product Code: YW1P-2EQ4A

The IDEC YW1P-2EQ4A is a durable pilot light designed for clear signaling with its amber LED lamp. The low-heat emission ensures energy efficiency and longevity. It operates on 24VAC/DC power and is compatible with a 22mm mounting system for easy installation. Safety is enhanced with IP20 finger-safe terminals, making it suitable for various industrial applications where reliable visual indication is essential.

Technical Specifications

Brand IDEC
Colour Amber
Degree of Protection IP65 (Front), IP20 (Terminals)
Insulation Resistance (MO) 100
Lamp Included
Lamp Type Included
Model Replacement Lamp Type
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 24
Series YW
Terminal Type Screw (M3.5)
