IDEC YW1P-1BUQM3S PILOT LIGHT WITH LED BLUE 230/240VAC FLUSH 22MM UNIBODY

Product Code: YW1P-1BUQM3S

The Unibody Pilot Light is a compact and efficient lighting solution designed for engineers. It features a built-in LED that emits a vibrant blue light. With a voltage range of 230/240VAC, it provides reliable illumination. The pilot light is flush-mounted with a 22mm mounting size, ensuring a seamless and professional installation. Additionally, it is equipped with IP20 finger safe terminals for added safety.

Technical Specifications

Brand IDEC
Degree of Protection IP65 (Front), IP20 (Terminals)
Insulation Resistance (MO) 100
Lamp Type Built-in LED
LED Colour Blue
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 230/240
Series YW
Terminal Type Screw (M3.5)
