Product Code: YW1P-1BUQ4S

The Unibody Pilot Light is a compact and efficient device designed for engineers. It features a built-in LED in a vibrant blue colour, providing clear visual indication. The light operates on both 24VAC and 24VDC power sources, offering flexibility in installation. With its flush design and 22mm mounting size, it seamlessly integrates into any control panel or equipment. Additionally, the device is equipped with IP20 finger safe terminals, ensuring safety during operation.

Brand	IDEC
Degree of Protection	IP65 (Front), IP20 (Terminals)
Insulation Resistance (MO)	100
Lamp Type	Built-in LED
LED Colour	Blue
Mounting Hole Diameter (mm)	22
Operational Temperature Range (°C)	-20 to +55
Rated Frequency (Hz)	50/60
Rated Voltage AC/DC (V)	24
Series	YW
Terminal Type	Screw (M3.5)

Pilot & Signalling Devices

IDEC YW1P-1BUQ4S PILOT LIGHT WITH LED BLUE 24VAC/DC FLUSH 22MM UNIBODY

Product Code: YW1P-1BUQ4S

Technical Specifications
