IDEC YW1P-2EH2G Pilot Light With LED Green 29.8 mm Dia Mount Hole

Product Code: YW1P-2EH2G

  • Non-Illuminated black pilot light
  • Operates in -25 to 70°C range
  • IP66 rated for high protection
  • Screw clamp connection type
  • Black plastic bezel with knob actuator
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 100/110
Lamp Included
Product Type Pilot Light With LED
Brand IDEC
Series YW
Actuator Type Knob
Bezel Type Black Plastic
Colour Black
Connection Type Screw Clamp
Degree of Protection IP66
Illumination Non-Illuminated
Lamp Type Included
Model Transformer Type
Operational Temperature -25 to 70 deg C
Power Loss 2 W
Resistance 5 kOhm
Storage Temperature -40 to 85 deg C
Terminal Type Screw (M3.5)

Description

The IDEC YW1P-2EH2G is a dome-shaped Pilot Light with a green LED transformer, designed for 22mm mounting. It operates efficiently on a 100/110VAC power supply and is engineered to emit low heat with an extended lifespan. For enhanced safety, it includes IP20 finger safe terminals. This pilot light is ideal for clear, long-lasting indication in various applications.
