When selecting a pilot light for industrial or commercial applications, technical specifications are paramount. This brown pilot light is designed to meet demanding environments with its robust features and compact dimensions. Its width of 9.6 mm, height of 39.5 mm, and depth of 27.7 mm make it suitable for installations where space is limited.
Engineered for performance across a wide range of temperatures, this pilot light operates efficiently from -30 to 70 degrees Celsius, ensuring reliability in diverse climates and conditions typical in Australia. The storage temperature mirrors the operational range but extends down to -40 degrees Celsius, offering flexibility during transport and storage.
The IP20 degree of protection indicates that the device is protected against solid objects over 12 mm in size but not against water ingress—ideal for indoor use where exposure to moisture isn't a concern. The product's lightweight design at just 0.009 kg makes it easy to handle during installation.
A notable feature is its screw terminal type with a tightening torque of 0.9 N-m, providing secure connections essential for maintaining electrical integrity under vibration or movement often found in industrial settings. The connection type utilizes screw clamps which are known for their reliability and ease of maintenance.
With a rated insulation voltage of up to 690 V and an impressive rated impulse withstand voltage capacity of 4 kV, this pilot light can handle substantial electrical loads while maintaining safety standards—a critical factor when working with high-voltage systems.
The contact configuration includes one normally closed (1NC) contact, which can be used effectively in various control circuit applications requiring fail-safe operations or emergency stop functions.
For wiring convenience, the connecting capacity accommodates flexible wires with ferrules ranging from 0.75-2.5 square millimeters as well as solid wires within the same range—ensuring compatibility with common wire sizes used in Australian installations. A wire stripping length requirement of 10 mm further simplifies preparation during setup.
Mounting the device is straightforward thanks to its front mounting type design—offering quick access and visibility once installed on panels or enclosures.
In terms of environmental considerations, it holds a degree of pollution rating at IP3 level—indicating suitability for environments where dust levels are controlled though not entirely absent; hence it's best suited for cleaner industrial settings rather than heavily polluted areas.
This comprehensive set of specifications ensures that this pilot light meets rigorous demands while providing dependable service throughout its lifecycle without compromising on quality or functionality.
