IDEC YW1P-2EM42PW Pilot Light With LED Pure White 22mm Dia Mount Hole

Product Code: YW1P-2EM42PW

  • Compact size: 9.6 mm width, 39.5 mm height
  • Operates between -30 to 70°C
  • IP20 protection for safety
  • Faston connection for easy setup
  • Front mounting simplifies installation
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC (V) 230/240
Lamp Included
Product Type Pilot Light With LED
Brand IDEC
Series YW
Ambient Temperature -30 to 70 deg C
Colour Brown
Connecting Capacity 1/2 x 0.75-2.5 sq-mm Flexible with Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible with Insulated Ferrule, 1/2 x 0.75-2.5 sq-mm Flexible, 1/2 x 0.75-2.5 sq-mm Solid
Connection Type Faston
Contact Configuration 1NC
Degree of Pollution IP3
Degree of Protection IP20
Depth 27.7 mm
Height 39.5 mm
Lamp Type Included
Model Transformer Type
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Storage Temperature -40 to 70 deg C
Terminal Type Screw (M3.5)
Tightening Torque 0.9 N-m
Width 9.6 mm
Wire Stripping Length 10 mm

Description

The IDEC YW1P-2EM42PW is a dome-type Pilot Light with an integrated LED transformer, emitting a pure white light. Designed for 230/240VAC systems, it ensures easy installation with a 22mm mounting size. The included LED lamp boasts low heat emission and extended durability. For enhanced safety, this pilot light is equipped with IP20 finger safe terminals.
