IDEC YW1P-2EQ4Y Pilot Light With LED Yellow 24VDC 29.8 mm Dia Mount Hole

Product Code: YW1P-2EQ4Y

  • Compact design: 9.8 mm wide, 39.5 mm high
  • Operates in extreme temps: -30 to 70°C
  • Easy screw clamp connection
  • IP20 protection rating
  • Built-in blue LED illumination
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Insulation Resistance (MO) 100
Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 24
Lamp Included
Product Type Pilot Light With LED
Brand IDEC
Series YW
Colour Light Blue
Connecting Capacity 0.75-2.5 sq-mm
Connection Type Screw Clamp
Degree of Pollution IP3
Degree of Protection IP20
Depth 56 mm
Height 39.5 mm
Illumination Illuminated
Lamp Type Built-In LED
LED Colour Blue
Model Replacement Lamp Type
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Voltage 24 VAC
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Weight 0.02 kg
Width 9.8 mm
Wire Stripping Length 8 mm

Description

The IDEC YW1P-2EQ4Y is a durable, full voltage pilot light featuring a yellow LED that provides low heat emission. Designed for 24VAC/DC systems, this unit offers easy installation with its 22mm dome-shaped mounting. It ensures user safety with IP20 finger safe terminals. Ideal for various industrial applications, this pilot light combines longevity and safety in a compact design.
