When selecting a pilot light for industrial or commercial applications, precision and reliability are paramount. This brown pilot light is engineered to meet demanding operational conditions with its robust specifications, making it a dependable choice for professionals in the electrical engineering and automation sectors.
With dimensions of 9.6 mm in width, 39.9 mm in height, and 48 mm in depth, this compact device fits seamlessly into various control panels while maintaining an unobtrusive profile. Its front mounting type ensures easy integration into existing systems without requiring extensive modifications.
Designed to withstand challenging environments, this pilot light operates efficiently across a wide temperature range from -25°C to 70°C. It can also be stored safely between -40°C and 70°C, ensuring durability even during downtime or transportation.
The unit's electrical characteristics are equally impressive. It features a rated insulation voltage of 690 V and a rated impulse withstand voltage of 4 kV, providing strong protection against electrical surges. The contact configuration is set at 2NO (two normally open contacts), offering flexibility for various signaling needs.
In terms of connectivity, the screw clamp connection type facilitates secure wiring with minimal effort. It supports a connecting capacity ranging from flexible wires with ferrules to solid conductors between 0.75 sq-mm and 2.5 sq-mm—ideal for diverse installation requirements. The wire stripping length is set at an optimal 10 mm for efficient preparation during setup.
Safety standards are not overlooked; the product boasts an IP20 degree of protection against solid objects larger than 12 mm, while its degree of pollution rating stands at IP3—suitable for indoor use where exposure to dust or moisture is moderate.
The terminal type employs screw connections with a tightening torque specification of 0.9 N-m, ensuring that all connections remain secure under mechanical stress or vibration—a critical feature in high-demand environments.
Weighing just 0.016 kg, this lightweight solution does not compromise on performance despite its minimal mass—facilitating ease of handling during installation or maintenance tasks.
In summary, this brown pilot light provides comprehensive functionality wrapped within durable construction parameters suitable for Australian technical audiences who prioritize factual decision-making based on precise specifications rather than emotive appeals.
