IDEC YW1P-2EQ0Y Pilot Light Without Lamp Yellow 250VAC 29.8 mm Dia Mount Hole

Product Code: YW1P-2EQ0Y

  • Black pilot light with momentary actuation
  • Durable metal bezel construction
  • Wide operating temp: -30 to 70°C
  • High protection rating: IP66, NEMA 1, 12, 13, etc.
  • Lightweight at just 0.091 kg
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Mounting Hole Diameter (mm) 22
Operational Temperature Range (°C) -20 to +55
Rated Frequency (Hz) 50/60
Rated Voltage AC/DC (V) 250
Insulation Resistance (MO) 100
Lamp Not Included
Product Type Pilot Light Without Lamp
Brand IDEC
Series YW
Actuation Type Momentary
Bezel Material Metal
Colour Black
Degree of Protection IP66
Lamp Type Not included
Maintained Position A, D, B
Model Replacement Lamp Type
NEMA Rating NEMA 1, 12, 13, 3, 3R, 3S, 4, 4x
Number of Positions 2
Operational Temperature -30 to 70 deg C
Storage Temperature -40 to 70 deg C
Terminal Type Screw (M3.5)
Weight 0.091 kg

Description

The IDEC YW1P-2EQ0Y is a yellow dome-type pilot light designed for durability and safety. It operates at 250VAC/DC and is suitable for 22mm mounting. The unit's terminals are IP20 finger safe, enhancing user protection during operation. This pilot light is engineered for low heat generation and extended lifespan, ensuring reliable indication in various applications.
