IDEC YW1P-2EQHS Dome Pilot Light with Built-In LED Blue 110VDC 22mm Dia Mount Hole

Product Code: YW1P-2EQHS

  • Operates at 120 VAC, 50/60 Hz
  • Light green illumination for visibility
  • Compact size: 9.8mm W x 39.5mm H x 56mm D
  • Screw clamp connection for secure fit
  • Built-in LED with IP20 protection
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 61.7D
Operating Voltage DC (V) 110
Operating Voltage AC (V) 110
Product Type Dome Pilot Light
Brand IDEC
Colour Light Green
Connecting Capacity 0.75-2.5 sq-mm
Connection Type Screw Clamp
Degree of Pollution IP3
Degree of Protection IP20
Depth 56 mm
Height 39.5 mm
Illumination Illuminated
Lamp Type Built-In LED
LED Colour Green
Model Dome Full Voltage - LED Lamp
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Voltage 120 VAC
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Weight 0.02 kg
Width 9.8 mm
Wire Stripping Length 8 mm

Description

The IDEC YW1P-2EQHS is a compact and efficient pilot light dome designed for 110V AC/DC applications with a 22mm mounting size. It features space-saving, 10mm thick contact blocks and a removable operator for ease of use. The metal bezel enhances durability, while the unibody design simplifies installation. Its large lens offers an expansive viewing angle, making it ideal for various industrial settings.
