IDEC YW1P-2EQHR Dome Pilot Light with Built-In LED Red 110VDC 22mm Dia Mount Hole

Product Code: YW1P-2EQHR

  • Operates at 120 VAC, 50/60 Hz
  • Bright red illumination
  • Compact size: 9.8 mm width
  • Screw clamp connection
  • Front mounting design
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29.6W x 24H x 61.7D
Operating Voltage DC (V) 110
Operating Voltage AC (V) 110
Product Type Dome Pilot Light
Brand IDEC
Colour Red
Connecting Capacity 0.75-2.5 sq-mm
Connection Type Screw Clamp
Degree of Pollution IP3
Degree of Protection IP20
Depth 56 mm
Height 39.5 mm
Illumination Illuminated
Lamp Type Built-In LED
LED Colour Red
Model Dome Full Voltage - LED Lamp
Mounting Type Front
Operational Temperature -30 to 70 deg C
Rated Frequency 50/60 Hz
Rated Voltage 120 VAC
Storage Temperature -40 to 70 deg C
Terminal Type Screw
Tightening Torque 0.9 N-m
Width 9.8 mm
Wire Stripping Length 8 mm

Description

The IDEC YW1P-2EQHR is a compact, dome-type pilot light designed for efficient use of space with its 10mm thick contact blocks. This red pilot light operates on 110V AC/DC and features a removable operator for easy maintenance. Its lightweight design ensures simple installation and handling. Ideal for various applications, this pilot light provides clear indication with its bright dome lens.

Documents

  • IPD Product Catalogue

    IPD Product Catalogue V17
