IDEC PLUG-IN TIMER 8 PIN 24VAC/DC SPDT GT3A-2AD24
Zoom
IDEC PLUG-IN TIMER 8 PIN 24VAC/DC SPDT GT3A-2AD24
Product Code: GT3A-2AD24
The Plug-in Multifunction Timer offers 4 selectable operation modes on each model. It features external start, reset, and pause inputs on 11 pin models. The timer is designed with a standard 8 pin base and includes power and output status indicating LEDs. It has a time range of 0.05s to 180H and operates with a rated input voltage of 24VAC/24VDC. The timer has Delayed SPDT + Instantaneous SPDT functionality and offers different modes of operation: A: ON-Delay 1, B: Interval 1, C: Cycle 1, D: Cycle 3.
Technical Specifications
Brand
IDEC
Contacts
Delayed SPDT + Instantaneous SPDT
Degree of Protection
IP40 (Timer), IP20 (Socket)
Input Voltage AC (V)
24
Input Voltage AC/DC (V)
24
Input Voltage DC (V)
12
Insulation Resistance (MO)
100
No. of Pins
8
Operational Temperature Range (°C)
-10 to +50
Output Voltage AC (V)
240 (3A) / 120 (5A)
Output Voltage DC (V)
30
Pollution Degree
2
Power Consumption (W)
0.8W (DC), 2.0VA (AC)
Series
GT3A
Standards and Approvals
EN 61812-1:2011, EN IEC 63000:2018
Storage Temperature (°C)
-30 - +70
Timing Range
0.1s - 180hrs
