IDEC GT5P-N10SA200 ON Delay Timers 200-240VAC Pin Terminal

Product Code: GT5P-N10SA200

  • Plug-in timer for easy installation
  • Operates on 200-240 VAC
  • Compact size: 29x36x81.5 mm
  • Long electrical life: 100,000 ops
  • CE, CSA, UL recognized
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Dimensions (mm) 29W x 36H x 81.5D
Operational Temperature Range (°C) -10 to 50
Weight (g) 54
Minimum Mechanical Life 20,000,000
Operating Humidity 35 to 85%
Minimum Electrical Life 100000
Resistance to Shock (m/s²) 98
Power Consumption (VA) 5
Voltage Range AC (V) 200 to 240
Product Type ON Delay Timers
Brand IDEC
Depth 81.5 mm
Electrical Life 100000 Operations
Height 36 mm
Humidity 45-85%
Mechanical Life 20000000 Operations
Operational Temperature -10 to 50 deg C
Rated Power 5 VA
Rated Voltage 200-240 VAC
Shock Resistance 98 ms
Standards and Approvals CE, CSA, UL Recognized File E55996
Terminal Type Pin
Weight 54 g
Width 29 mm

Description

The IDEC GT5P-N10SA200 is a plug-in timer designed for precision timing control in industrial applications. It features an on-delay function with a time range of 0.2 seconds to 10 seconds and operates on a 200-240V AC power supply. This 8-pin timer includes SPDT contacts, ensuring versatile connectivity for various electrical circuits. Its compact design allows for easy installation and integration into existing systems.
