Schmersal 101193148 Magnetic Safety Sensor

Product Code: 101193148

  • Operates at 75 VDC and 0.4 A
  • Durable with 25M cycle life
  • Quasi-flush mount design
  • IP67 for superior protection
  • Withstands -25 to 70°C temps
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Safety Sensor
Brand SCHMERSAL
Series BNS36
Actuating Element Magnet
Degree of Protection IP67
Housing Material Glass Fibre Reinforced Thermoplastic
Mechanical Life 25000000 Cycles
Mounting Type Quasi-Flush
Number of Poles 4
Operational Temperature -25 to 70 deg C
Rated Current 0.4 A
Rated Frequency 5 Hz
Rated Power 10 W
Rated Voltage 75 VDC
Sensor Size 13 mm L x 88 mm W x 25 mm H
Standards and Approvals BG-GS-ET-14; EN IEC 60947-5-3; EN ISO 13849-1
Vibration Resistance 10-55 Hz

Description

<p>When selecting a product for industrial and commercial applications, it&amp;#39;s crucial to focus on specifications that ensure reliability and efficiency. This particular product stands out with its robust features tailored for demanding environments.</p><p>Operating at a rated voltage of 75 VDC and a current of 0.4 A, this device provides a reliable power output of 10 W. Its operating frequency is set at 5 Hz, making it suitable for various technical applications where consistent performance is required. The mechanical life of the product reaches up to an impressive 25 million cycles, ensuring longevity and durability in high-use scenarios.</p><p>The quasi-flush mounting type allows for seamless integration into existing systems without taking up unnecessary space or requiring extensive modifications. Constructed from glass fibre reinforced thermoplastic, the housing material offers exceptional strength while maintaining lightweight properties—ideal for environments where durability is paramount.</p><p>With an IP67 degree of protection, this product is dust-tight and can withstand immersion in water up to one meter deep, making it highly resistant to harsh environmental conditions. It operates efficiently within a temperature range of -25 to 70 degrees Celsius, accommodating both cold storage facilities and warmer industrial setups.</p><p>Compliance with standards such as BG-GS-ET-14, EN IEC 60947-5-3, and EN ISO 13849-1 assures users that this product meets rigorous safety and performance benchmarks required by international regulations.</p><p>The actuating element features a magnet which enhances its operational precision in automation processes. Measuring at just 13 mm in length by 88 mm in width by 25 mm in height, the sensor&amp;#39;s compact size does not compromise functionality but rather supports versatile installation options across different systems.</p><p>Additionally, the vibration resistance ranging from 10 to 55 Hz ensures stable operation even in settings subject to mechanical disturbances or vibrations common in industrial environments.</p><p>In summary, this product delivers dependable performance backed by solid engineering principles suitable for professionals seeking quality components that meet stringent industry standards while providing ease of installation and maintenance-free operation over extended periods.</p>
