Schmersal 103042303 Magnetic Safety Sensor 2NC+1NO 0.3m Cable

Product Code: 103042303

  • Rated for 0.25 A current and 3 W power
  • Stainless steel housing, IP69 protection
  • Operates in -25 to 80°C temperature range
  • Compact size: 14x88x27 mm sensor dimensions
  • Durable against shock (30 g) & vibration (10-55 Hz)
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Magnetic Safety Sensor
Brand SCHMERSAL
Cable Length 0.3 m
Contact Configuration 2NC+1NO
Degree of Protection IP69
Housing Material Stainless Steel
Operational Temperature -25 to 80 deg C
Rated Current 0.25 A
Rated Frequency 5 Hz
Rated Power 3 W
Sensor Size 14 mm L x 88 mm W x 27 mm H
Shock Resistance 30 g/11 ms
Vibration Resistance 10-55 Hz
Wire Size 23 sq-mm

Description

<p>For professionals in the industrial and commercial sectors, selecting the right product is a decision driven by technical specifications and reliability. This particular product offers robust features suitable for demanding environments.</p><p>The unit operates with a rated current of 0.25 A and a power rating of 3 W, making it efficient for various applications without excessive energy consumption. Its rated frequency stands at 5 Hz, which should be factored into your specific application requirements. </p><p>A key feature is its contact configuration of 2NC+1NO, providing flexibility in control systems where both normally closed and normally open contacts are needed. The device comes with a cable length of 0.3 m, ensuring ease of installation while minimizing excess wiring clutter.</p><p>Constructed from stainless steel, the housing material ensures durability and resistance to corrosion—a critical factor in maintaining operational integrity over time. The degree of protection is IP69, indicating that this product can withstand high-pressure water jets and complete dust ingress—ideal for harsh environments where cleanliness or exposure to elements is a concern.</p><p>Operational temperature ranges from -25&amp;#176;C to 80&amp;#176;C, offering versatility across different climates or conditions without compromising performance. With dimensions measuring 14 mm L x 88 mm W x 27 mm H, the sensor size allows for compact installations where space may be limited.</p><p>The wire size is specified at 23 sq-mm, supporting adequate current flow while maintaining structural integrity under mechanical stress or thermal expansion. Additionally, the shock resistance capability of up to 30 g/11 ms ensures that this product can handle sudden impacts without failure—an essential attribute in dynamic settings such as manufacturing plants or transportation sectors.</p><p>Vibration resistance between frequencies of 10-55 Hz further enhances its suitability for environments subject to continuous movement or oscillations—ensuring reliable operation even under challenging conditions.</p><p>This comprehensive set of features positions this product as an optimal choice for those seeking dependable performance combined with resilience against environmental factors common within industrial applications.</p>
