<p>This RCBO is designed to provide reliable protection in both industrial and commercial settings, ensuring safety and compliance with stringent standards. With a rated current of 6 A, it effectively safeguards electrical circuits from overloads and short circuits. The device operates at a rated voltage of 400/415 VAC, making it suitable for a wide range of applications.</p><p>Built to withstand harsh conditions, the RCBO boasts an impressive impulse withstand voltage of 4 kV and insulation voltage of 500 V. Its power loss is minimal at just 3.52 W, enhancing energy efficiency in your installations. The product features a robust design with dimensions measuring 53.4 mm in width, 117.5 mm in height, and 71.6 mm in depth.</p><p>The RCBO is equipped with a three-pole plus neutral (3P+N) configuration, providing comprehensive circuit protection across multiple phases. It adheres to the highest safety standards as indicated by its compliance with IEC 61009-1, IEC 61009-2-2, and AS/NZS 61009-1 certifications.</p><p>With an IP20 degree of protection, this device is safeguarded against solid objects larger than 12 mm but should be installed within appropriate enclosures for optimal performance in dusty or wet environments. The unit&#39;s electrical durability extends up to an impressive 10,000 cycles, ensuring long-term reliability.</p><p>For those concerned about installation flexibility, this RCBO supports various cable cross sections: from single-core cables ranging between 1-25 sq-mm to multi-wired cables between 1-16 sq-mm. It also accommodates busbar connections up to a capacity of 10 sq-mm.</p><p>This Type A residual current device offers instantaneous operating characteristics with an undelayed earthing switch type for rapid response during fault conditions. Its overvoltage category III classification ensures resilience against transient voltages typically found in industrial settings.</p><p>Designed for chassis mounting with bottom power supply connection points, this RCBO fits seamlessly into existing setups without requiring extensive modifications. Its curve type C characteristic means it&#39;s suitable for general-purpose use where moderate levels of surge currents are expected.</p><p>Operating efficiently within ambient temperatures ranging from -5&#176;C to +55&#176;C makes it versatile enough for varied climatic conditions across Australia while maintaining optimal functionality throughout its lifecycle.</p>
