Panasonic GX-F8A Rectangular Inductive Proximity Sensor NO NPN-Output 1m L Cable

Product Code: GX-F8A

  • Compact proximity sensor with 0-2.1 mm range
  • Operates on 12-24 VDC, <15 mA current
  • Durable PBT housing, IP68/IP68G rated
  • Functions in -40 to 85°C environments
  • Orange LED operation indicator
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Rectangular Inductive Proximity Sensor
Brand PANASONIC
Cable Length 1 m
Cable Type 3-core oil, heat and cold resistant cabtyre cable
Degree of Protection IP68, IP68G
Housing Material PBT
Humidity 35-95%
Insulation Resistance 50 MOhm
Operation Indicator Orange LED ON
Operational Temperature -40 to 85 deg C
Rated Current <15 mA
Rated Voltage 12-24 VDC
Relative Humidity 35 to 95%
Sensing Range 0-2.1 mm
Sensor Type Front Sensing
Shock Resistance 10000 ms
Utilisation Category DC-12 or DC-13
Weight 15 g

Description

<p>When it comes to reliable sensing solutions in industrial and commercial settings, this proximity sensor stands out as a dependable choice. Designed with precision, it offers a sensing range of 0 to 2.1 mm, making it suitable for applications requiring close-range detection.</p><p>Operating efficiently within a rated voltage of 12-24 VDC and drawing less than 15 mA of current, this sensor is both energy-efficient and versatile. Its robust construction features a PBT housing material known for its durability and resistance to harsh environments. This ensures the sensor can withstand challenging conditions without compromising performance.</p><p>One of the key attributes of this proximity sensor is its impressive degree of protection. With an IP68 rating, it is dust-tight and protected against continuous immersion in water. Additionally, the IP68G rating indicates enhanced resilience against oils and lubricants—ideal for demanding industrial environments.</p><p>This sensor also boasts an operational temperature range from -40 to 85 degrees Celsius, allowing it to function effectively in extreme temperatures often encountered in Australian climates. The humidity tolerance between 35% and 95% further enhances its adaptability across various environmental conditions.</p><p>Weighing just 15 grams, the sensor is lightweight yet engineered for high shock resistance up to 10000 ms—a testament to its rugged design that can endure mechanical stresses without failure.</p><p>The practical aspects include a cable length of 1 meter which provides sufficient reach for most installations while maintaining neatness in setup. Furthermore, with an insulation resistance of 50 MOhm, safety during operation is assured by minimizing potential electrical hazards.</p><p>For ease of operation monitoring, the orange LED indicator lights up when active—providing clear visual confirmation at a glance that the device is functioning correctly.</p><p>In summary, this proximity sensor combines robustness with sophisticated engineering tailored for precise short-range detection tasks across various industries—from automation systems to building management setups. Its comprehensive feature set ensures reliability under diverse operational conditions making it an ideal component for those seeking quality performance backed by technical excellence.</p>
