Panasonic GX-H12A-P Rectangular Inductive Proximity Sensor NO PNP-Output 1m L Cable

Product Code: GX-H12A-P

  • Sensing range up to 3.3 mm
  • Operates on 12-24 VDC
  • Durable PBT housing
  • IP68 protection rating
  • Orange LED operation indicator
In Stock Low Stock Out Of Stock Please See Attributes

Specifications

Product Type Rectangular Inductive Proximity Sensor
Brand PANASONIC
Cable Length 1 m
Cable Type 3-core oil, heat and cold resistant cabtyre cable
Degree of Protection IP68, IP68G
Housing Material PBT
Humidity 35-95%
Insulation Resistance 50 MOhm
Operation Indicator Orange LED ON
Operational Temperature -40 to 85 deg C
Rated Current <15 mA
Rated Voltage 12-24 VDC
Relative Humidity 35 to 95%
Sensing Range 0-3.3 mm
Sensor Type Top Sensing
Shock Resistance 10000 ms
Utilisation Category DC-12 or DC-13
Weight 20 g

Description

<p>This robust proximity sensor is designed for industrial and commercial applications, offering reliable performance with a sensing range of 0-3.3 mm. It operates efficiently within a rated voltage of 12-24 VDC and maintains a low rated current consumption of less than 15 mA, making it energy-efficient for continuous use.</p><p>Constructed from durable PBT housing material, this sensor is built to withstand demanding environments. Its impressive IP68 and IP68G ratings ensure excellent protection against dust and water ingress, allowing it to perform reliably even in harsh conditions. The operational temperature range extends from -40 to 85 degrees Celsius, providing versatility across various climates and industrial settings.</p><p>The proximity sensor features an orange LED operation indicator that lights up when the device is active, providing clear visual confirmation of its status. With a cable length of 1 meter, installation flexibility is enhanced while ensuring secure connectivity.</p><p>Designed with resilience in mind, the sensor boasts shock resistance up to 10,000 ms and humidity tolerance ranging from 35% to 95%. This makes it suitable for environments where mechanical stress or moisture levels might otherwise impact performance.</p><p>Weighing just 20 grams, this lightweight sensor offers ease of integration without compromising on durability or functionality. Additionally, the insulation resistance stands at an impressive 50 MOhm, ensuring electrical safety and reliability throughout its lifecycle.</p><p>Whether you&amp;#39;re working in automation systems or need precise object detection capabilities in manufacturing processes, this proximity sensor delivers dependable performance backed by solid technical specifications.</p>
